COMPRESOR FRACCIONADO DANFOSS HUAYI 1/4 HP R134A
COMPRESOR FRACCIONADO DANFOSS HUAYI 1/4 HP R134A
Precio habitual
$ 2,561.81 MXN
Precio habitual
Precio de oferta
$ 2,561.81 MXN
Precio unitario
/
por
Impuesto incluido.
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
Compartir
SKU: 123B1572
COMP FRACCIONARIO DANFOSS 1/4L R134A 115v
| Gross weight | 10.8 Kg |
| Net weight | 10.6 Kg |
| Volume | 11.4 Liter |
| EAN | 5702428584555 |
| Applications | HBP MBP |
| Approval standard | UL |
| Auxiliary winding resistance (start winding) for single-phase compressors [Ohm] | 6.8 |
| Brand technique | Reciprocating compressor |
| Capacity control | Fixed speed |
| Colour | Black |
| Compressor power supply [V/Ph/Hz] | 115/1/60 |
| Configuration code | Single |
| Cut in current HST 60Hz [A] | 28.2 A |
| Description | GLY80RDa |
| Discharge connection angle [°] | 0 ° |
| Discharge connection comments | Rubber plug |
| Discharge connection diameter [mm] | 4.9 mm |
| Discharge connection height [mm] | 108 mm |
| Discharge connection material | Copper |
| Economizer | No |
| Family | L |
| Frequency [Hz] | 60 |
| Height from baseplate [mm] | 186 mm |
| High value of nominal voltage at 60Hz [V] | 115 V |
| High value of voltage range at 60Hz [V] | 132 V |
| Low value of nominal voltage at 60Hz [V] | 115 V |
| Low value of voltage range at 60Hz [V] | 98 V |
| LRA HST 60Hz [A] | 28.2 A |
| Main winding resistance for single-phase compressors [Ohm] | 1.7 |
| MCC | 6.80 A |
| Model number | GLY80RDa |
| Motor type | CSIR |
| No. of phases (compressor) | 1 |
| Nominal cooling capacity 60 kBTU/h | 3.11 kBtu/h |
| Nominal cooling capacity at 60Hz | 0.9 kW |
| Oil quantity [cm3] | 350 cm³ |
| Oil type | POE |
| Packing format | Single pack |
| Packing quantity | 1 |
| Process connection angle [°] | 50 ° |
| Process connection comments | Rubber plug |
| Process connection diameter [mm] | 6.5 mm |
| Process connection material | Copper |
| Product group | Hermetic compressors |
| Product Name Description | Reciprocating compressor L |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Refrigerant charge [kg] [Max] | 1.15 kg |
| Refrigerants | R134a |
| Rotational speed at 60Hz [rpm] | 3600 rpm |
| SCIP dossier no. | cd1d92df-acc4-43d9-8eb6-bb380e61d93f |
| SCIP dossier product name | GL |
| Segment usage | Refrigeration MT |
| Start capacitor capacitance | 200 µF |
| Suction connection angle [°] | 20 ° |
| Suction connection diameter [mm] | 6.5 mm |
| Suction connection height [mm] | 113 mm |
| Suction connection material | Copper |
| Swept volume [cm3] | 8.1 cm³ |
| Technology | Reciprocating |
| Total height [mm] | 192 mm |
| Type | GLY80 |
| Voltage 60Hz [V] | 115 V |
| Voltage 60Hz [V] [Max] | 115 V |
| Winding temperature short term [°C] [Max] | 135 °C |
| Winding temperature stat [°C] [Max] | 115 °C |
59 en existencias
